High-Precision Large Diameter Machined Discs with Micron-Level Flatness and Semiconductor-Grade Finishes

نام تجاری:	Hongsinn
شماره مدل:	HS-344
حداقل مقدار سفارش:	1، قطعه / قطعه
قیمت:	USD,0.78-7.59,Piece/Pieces
شرایط پرداخت:	L/C، D/A، D/P، T/T، وسترن یونیون، مانی گرام
توانایی تامین:	5000,قطعه/قطعه,ماه

اطلاعات جزئیات

توضیح محصول

اطلاعات جزئیات

محل منبع:

گوانگدونگ

گواهی:

ISO9001:2015 ISO14001

نام محصول:

ماشینکاری قطعات

درمان سطحی:

آندایزینگ، پولیش، کروم به عنوان درخواست شما

خدمات:

ماشینکاری CNC OEM / ODM

درخواست به:

هر قطعه ماشینکاری cnc OEM

نمونه:

نیاز به پرداخت هزینه نمونه

تحمل:

+/-0.01-0.005 میلی متر

فرآیند:

ماشینکاری Cnc + برش

ویژگی:

با دوام و دقت بالا

رنگ:

رنگ سفارشی

زمان تحویل:

3-7 روز برای سفارش نمونه، 10-15 روز برای سفارش فله پس از آن

جزئیات بسته بندی:

فوم EPE داخل و کارتن بیرون یا فوم EPE داخل و چوبی بیرون

قابلیت ارائه:

5000,قطعه/قطعه,ماه

توضیح محصول

High-Flatness Large Diameter Machined Discs

Product Overview

As industry-leading experts in precision CNC machining, we specialize in resolving manufacturing challenges associated with large-format, high-tolerance, and thin-walled disc-shaped components. This series of precision indexing baseplates is custom-engineered for semiconductor manufacturing, precision robotics, and high-end automation systems, delivering exceptional structural stability and repeatable positioning accuracy—even within extreme industrial environments.

Leveraging over 15 years of precision machining expertise, we employ unique stress-relief techniques to ensure that our large-diameter baseplates maintain micron-level flatness following complex cutting operations, thereby meeting the most stringent industrial standards.

Core Technical Advantages

Micron-Level Geometric Tolerance Control

Utilizing advanced 4-axis and 5-axis CNC machining centers, we complete the machining of all complex hole patterns, cavities, and dowel pin bores in a single setup. This process eliminates cumulative errors at the source, consistently maintaining critical positional tolerances within ±0.01 mm while ensuring flatness meets rigorous assembly requirements.

Superior Material Stress Management

For large-diameter components made from aluminum alloys and stainless steel, we combine specialized heat treatments with vibration aging processes to effectively eliminate internal stresses. Even under prolonged use or within semiconductor vacuum environments, our components exhibit minimal deformation, ensuring sustained stability and precision.

Semiconductor-Grade Surface Finishes

We offer surface finishing solutions that comply with Cleanroom standards, including:

Hard Anodizing
Electroless Nickel Plating
Electropolishing

These finishes ensure that our baseplates possess high corrosion resistance, low outgassing rates, and superior surface hardness—meeting the exacting demands of the semiconductor and high-end automation industries.

100% Digital Quality Assurance

Every baseplate undergoes comprehensive validation through CMM (Coordinate Measuring Machine) inspection, optical projection, and laser surface roughness testing. Each component features a unique serial number engraved on its edge, enabling full traceability of production batches and inspection data to guarantee the precision and reliability of every delivered part.

Manufacturing Capabilities

Machining Equipment	15 CNC Tapping Center, 18 CNC Lathes, 25 auto lathe, 4 MAZAK five axis CNC, etc.
Processing	Turning, Milling, Drilling, Tapping, Knurling, Wire EDM, Grinding, Engraving, Knurling, etc.
Tolerance	±0.005mm
Material Workable	Copper, Steel, Aluminum, Brass, Stainless Steel, Titanium, Plastics (PEEK, ABS, Acrylic, Delrin, PP, PMMA, PC, POM, polyethylene, PVC, Nylon), Organic Glass, Carbon Fiber, Wood, etc. Other materials as requested.
Surface Treatment	Nickel Plating, Anodizing, Chrome Plating, Brushing, Polishing, Blackening, Powder coating, Sandblasting, de-burring, Electrophoresis, Passivation, etc.
Drawing Format	JPEG, PDF, DWG, DXF, IGS, STEP, CAD
MOQ	No MOQ Required, 1 PC is acceptable
Lead Time	1-30 days based on order quantity
Quality System	100% inspection before shipment (CMM, Projector, Gauge and other inspection tools)
Size	Customization
Standard	OEM/ODM
FOB Port	Shenzhen, China
Payment	50% T/T in advance, 50% before shipment. Accept T/T, L/C, Escrow, PayPal, Western Union
Packing	Carton box, wooden case, pallet, etc.
Shipping	By sea, by air, by DHL, UPS, FedEx, TNT or EMS, etc.

Frequently Asked Questions

Are you a trade company or manufacturer?

We are a manufacturer with more than 14 years of experience in CNC machining and sheet metal fabrication.

Can you protect my business? Will my drawing be safe after you get it?

Yes, we can sign an NDA before you send the drawing.

Available for customized design drawings?

Yes, we accept CAD, STEP, IGS, PDF, Solidworks, etc.

Do you provide samples?

Yes, there is a sample charge, which can be refunded when you place an order.

How soon can I get your quotation?

Within 12 hours.

What's the lead time?

5-25 working days, based on order quantity.
